Viewsonic VPC12-WPO-16 embedded computer 2.3 GHz Intel® Core™ i5 256 GB SSD 8 GB
Product overview & specifications
Windows 10, Intel Core i5-8259U, DDR4 8GB, 256GB, M.2, Microphone, HDMI x1, Audio line out, x4 USB 3.0 Type-A, x1 Type-C, 12 / 19V, 65W, 202 x 119 x 30mm, 800g
The ViewSonic® VPC12-WPO-16 slot-in PC is the ideal integrated solution for the ViewBoard® interactive displays and presentation displays. With dual-band Wi-Fi and Bluetooth, a powerful Intel® Core™ i5-8259U Processor, 8GB DDR4 SO-DIMM memory, and 256GB SSD storage, the VPC12-WPO-16 contains the computing power needed to operate CPU intensive applications.
| Processor | |
|---|---|
| Processor generation | 8th gen Intel® Core™ i5 |
| Processor manufacturer | Intel |
| Processor frequency | 2.3 GHz |
| Processor family | Intel® Core™ i5 |
| Processor model | i5-8259U |
| Processor cores | 4 |
| Processor boost frequency | 3.8 GHz |
| Processor cache | 6 MB |
| System bus rate | 4 GT/s |
| Processor threads | 8 |
| Thermal Design Power (TDP) | 28 W |
| Configurable TDP-down | 20 W |
| Configurable TDP-down frequency | 1.1 GHz |
| Maximum internal memory supported by processor | 32 GB |
| Memory | |
| Internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 1x SO-DIMM |
| Storage | |
| Total storage capacity | 256 GB |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| SSD interface | M.2 |
| SSD capacity | 256 GB |
| Graphics | |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| On-board graphics card model | Intel Iris Plus Graphics 655 |
| Maximum on-board graphics card memory | 32 GB |
| On-board graphics card 4K support | Yes |
| Graphics card HDMI ports quantity | 1 |
| Network | |
| Bluetooth Low Energy (BLE) | Yes |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Bluetooth | Yes |
| Bluetooth version | 4.2 |
| Ports & interfaces | |
| USB 2.0 ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 0 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Performance | |
| Product colour | Black |
| Built-in display | No |
| Software | |
| Operating system installed | Windows 10 Pro |
| Operating system architecture | 64-bit |
| Processor special features | |
| Intel Flex Memory Access | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Embedded options available | No |
| Intel TSX-NI | No |
| Intel 64 | Yes |
| Intel Stable Image Platform Program (SIPP) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel Clear Video Technology | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Power | |
| Power consumption (typical) | 65 W |
| DC input voltage | 12 / 19 V |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Certificates | |
| Certification | CE EMC, CE LVD, CE RED, RoHS, WEEE, BIS, WPC |
| Weight & dimensions | |
| Width | 202 mm |
| Depth | 119 mm |
| Height | 30 mm |
| Weight | 800 g |
| Package width | 254 mm |
| Package depth | 196 mm |
| Package height | 77 mm |
| Package weight | 1.1 kg |
