Lindy 16 Port + 2 SFP Gigabit Managed Switch PoE

BrandLindy
SKU / Part number25048
Need a bulk quote or product advice?
Speak to our team about your requirements.
Contact sales →
Product overview & specifications
16 Port + 2 SFP Gigabit Managed Switch PoE
Add 16 Gigabit ports to a network infrastructure using a convenient fibre uplink via 2 SFP+ slots, while providing power to compatible devices using PoE Professional Layer 2 management features for superior network traffic optimisation and control Features Jumbo Frame support and IGMP snooping for effective AV Over IP installation integration DDM for consistent critical information monitoring of the transmitted and received signals 2 Year Warranty This advanced Lindy 16 Port Gigabit switch with PoE provides a high performance, intelligent expansion to a distributed IP network, while utilising dual SFP+ module slots for longer distance uplink, ideal for larger scale or multi-building installations. All RJ-45 ports are PoE IEEE 802.3at/af compliant providing up to 30W of power to compatible devices, simplifying the whole installation. Supporting full Layer 2 management, traffic can be separated and managed effectively via advanced VLAN features, alongside QoS for independent traffic prioritisation and IGMP Snooping for optimised multicast stream listening, while the user can efficiently control the network via Web Gui, Telnet or command line. Featuring virtual stacking, this switch can also be integrated alongside multiple switches for even larger scale installations, while controlled and managed as a single switch. Optical Digital Diagnostic Monitoring support also ensures the user is provided with consistent critical information regarding the status of both the transmitter and received signals, ensuring faults can be identified and resolved with minimum disruption to the system.
Ports & interfaces
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
SFP module slots quantity 2
Basic switching RJ-45 Ethernet ports quantity 16
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Console port RS-232
Mini-SAS stacking port data rate (max) 36 Gbit/s
Network
IGMP snooping Yes
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Full duplex Yes
VLAN support Yes
Spanning tree protocol Yes
Port mirroring Yes
Link aggregation Yes
Flow control support Yes
Broadcast storm control Yes
Auto MDI/MDI-X Yes
10G support No
Auto-negotiation Yes
Virtual LAN features Protocol-based VLAN, Voice VLAN
Virtual LAN features
VLAN support Yes
Virtual LAN features Protocol-based VLAN, Voice VLAN
Performance
Packet buffer memory 4 MB
Stackable Yes
Auto-negotiation Yes
Firmware upgradeable Yes
Harmonized System (HS) code 85176990
Technical details
Product colour Black
Stackable Yes
Housing material Metal
Firmware upgradeable Yes
Rack mounting Yes
Management features
Switch type Managed
Web-based management Yes
System event log Yes
Quality of Service (QoS) support Yes
Configuring Location Settings (CLI) Yes
Optical fiber
Fiber ethernet cabling technology 1000BASE-LX, 1000BASE-SX
Data transmission
Jumbo frames 9600
Packet buffer memory 4 MB
MAC address table 8000 entries
Switching capacity 36 Gbit/s
Jumbo frames support Yes
Forwarding rate 14.88 Mpps
Security
Authentication Port-based authentication
Security algorithms SSH-2, SSL/TLS
MAC address filtering Yes
IGMP snooping Yes
DHCP features DHCP relay, DHCP server, DHCP snooping
Certificates
Certification CE, UKCA, FCC, RoHS 2.0, REACH
Memory
Packet buffer memory 4 MB
Design
Product colour Black
Stackable Yes
LED indicators Activity, Link, PoE, Power
Housing material Metal
Certification CE, UKCA, FCC, RoHS 2.0, REACH
Rack mounting Yes
Indication
LED indicators Activity, Link, PoE, Power
Power
AC input voltage 100 - 240 V
AC input frequency 50 Hz
Power consumption (typical) 15 W
Power source AC
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port 30 W
Total Power over Ethernet (PoE) budget 235 W
Power over Ethernet (PoE) ports quantity 16
Power over Ethernet (PoE) Yes
Operational conditions
Storage temperature (T-T) -20 - 80 °C
Operating temperature (T-T) 0 - 45 °C
Operating relative humidity (H-H) 5 - 90%
Weight & dimensions
Width 330 mm
Depth 210 mm
Height 44 mm
Weight 2.52 kg
Packaging data
Rack mount kit Yes
Quick start guide Yes
User guide Yes
Manual Yes
Cables included AC
Logistics data
Harmonized System (HS) code 85176990
Packaging content
Rack mount kit Yes
Quick start guide Yes
User guide Yes
Manual Yes
Cables included AC
Lindy 16 Port + 2 SFP Gigabit Managed Switch PoE

Lindy 16 Port + 2 SFP Gigabit Managed Switch PoE

£187.20
Skip to product information
Lindy 16 Port + 2 SFP Gigabit Managed Switch PoE

Lindy 16 Port + 2 SFP Gigabit Managed Switch PoE

£187.20
16 Port + 2 SFP Gigabit Managed Switch PoE
Add 16 Gigabit ports to a network infrastructure using a convenient fibre uplink via 2 SFP+ slots, while providing power to compatible devices using PoE Professional Layer 2 management features for superior network traffic optimisation and control Features Jumbo Frame support and IGMP snooping for effective AV Over IP installation integration DDM for consistent critical information monitoring of the transmitted and received signals 2 Year Warranty This advanced Lindy 16 Port Gigabit switch with PoE provides a high performance, intelligent expansion to a distributed IP network, while utilising dual SFP+ module slots for longer distance uplink, ideal for larger scale or multi-building installations. All RJ-45 ports are PoE IEEE 802.3at/af compliant providing up to 30W of power to compatible devices, simplifying the whole installation. Supporting full Layer 2 management, traffic can be separated and managed effectively via advanced VLAN features, alongside QoS for independent traffic prioritisation and IGMP Snooping for optimised multicast stream listening, while the user can efficiently control the network via Web Gui, Telnet or command line. Featuring virtual stacking, this switch can also be integrated alongside multiple switches for even larger scale installations, while controlled and managed as a single switch. Optical Digital Diagnostic Monitoring support also ensures the user is provided with consistent critical information regarding the status of both the transmitter and received signals, ensuring faults can be identified and resolved with minimum disruption to the system.
Ports & interfaces
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
SFP module slots quantity 2
Basic switching RJ-45 Ethernet ports quantity 16
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Console port RS-232
Mini-SAS stacking port data rate (max) 36 Gbit/s
Network
IGMP snooping Yes
Copper ethernet cabling technology 10BASE-T, 100BASE-TX, 1000BASE-T
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Full duplex Yes
VLAN support Yes
Spanning tree protocol Yes
Port mirroring Yes
Link aggregation Yes
Flow control support Yes
Broadcast storm control Yes
Auto MDI/MDI-X Yes
10G support No
Auto-negotiation Yes
Virtual LAN features Protocol-based VLAN, Voice VLAN
Virtual LAN features
VLAN support Yes
Virtual LAN features Protocol-based VLAN, Voice VLAN
Performance
Packet buffer memory 4 MB
Stackable Yes
Auto-negotiation Yes
Firmware upgradeable Yes
Harmonized System (HS) code 85176990
Technical details
Product colour Black
Stackable Yes
Housing material Metal
Firmware upgradeable Yes
Rack mounting Yes
Management features
Switch type Managed
Web-based management Yes
System event log Yes
Quality of Service (QoS) support Yes
Configuring Location Settings (CLI) Yes
Optical fiber
Fiber ethernet cabling technology 1000BASE-LX, 1000BASE-SX
Data transmission
Jumbo frames 9600
Packet buffer memory 4 MB
MAC address table 8000 entries
Switching capacity 36 Gbit/s
Jumbo frames support Yes
Forwarding rate 14.88 Mpps
Security
Authentication Port-based authentication
Security algorithms SSH-2, SSL/TLS
MAC address filtering Yes
IGMP snooping Yes
DHCP features DHCP relay, DHCP server, DHCP snooping
Certificates
Certification CE, UKCA, FCC, RoHS 2.0, REACH
Memory
Packet buffer memory 4 MB
Design
Product colour Black
Stackable Yes
LED indicators Activity, Link, PoE, Power
Housing material Metal
Certification CE, UKCA, FCC, RoHS 2.0, REACH
Rack mounting Yes
Indication
LED indicators Activity, Link, PoE, Power
Power
AC input voltage 100 - 240 V
AC input frequency 50 Hz
Power consumption (typical) 15 W
Power source AC
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port 30 W
Total Power over Ethernet (PoE) budget 235 W
Power over Ethernet (PoE) ports quantity 16
Power over Ethernet (PoE) Yes
Operational conditions
Storage temperature (T-T) -20 - 80 °C
Operating temperature (T-T) 0 - 45 °C
Operating relative humidity (H-H) 5 - 90%
Weight & dimensions
Width 330 mm
Depth 210 mm
Height 44 mm
Weight 2.52 kg
Packaging data
Rack mount kit Yes
Quick start guide Yes
User guide Yes
Manual Yes
Cables included AC
Logistics data
Harmonized System (HS) code 85176990
Packaging content
Rack mount kit Yes
Quick start guide Yes
User guide Yes
Manual Yes
Cables included AC
