Lenovo ES-511 serial server RS-232/422/485
Product overview & specifications
Ethernet to Serial Device Server, 1 x RS-232/422/485 Port, 1000000 baud, 1 x RJ-45, 10/100Base TX, DIN Rail
Ethernet to Serial Device with 1 Port software selectable as RS232, RS422/485 Full duplex or RS422 Half duplex. ES-511 has removable Screw Terminals Blocks for easy wiring, a slim 'end on' case and integral DIN rail mount. Our Industrial Ethernet to Serial has an operating temperature range of -30 to +80 degrees Celsius and with +5VDC to +30VDC Dual input reverse polarity protected power supply making it perfect for industrial applications. Data transfer rates up to 1,000,000 baud, coupled with 1Mbit/s line drivers deliver uncompromising performance. Our Industrial ES range provides simple instant networked serial ports in demanding environments. Serial Port Tunneling allows serial cable replacement over any distance, no software required. Suitable to be wired into existing power and network infrastructure or can be used with our PW-600 power supply.
- 1 Port RS-232/422/485
- Industrial Ethernet to Serial Device Server
- Data rate from 110 to 921,600 baud
- Removable, colour-coded, number terminal blocks
- 30°C to +80°C Temperature range
- Robust, Slim Design, Integrated DIN rail mount
- 1 Port RS-232/422/485
- Industrial Ethernet to Serial Device Server
- Data rate from 110 to 921,600 baud
- Removable, colour-coded, number terminal blocks
- 30°C to +80°C Temperature range
- Robust, Slim Design, Integrated DIN rail mount
| Technical details | |
|---|---|
| Package width | 22.6 mm |
| Package length | 11.4 cm |
| Package height | 99 mm |
| Serial ports quantity | 1 |
| Serial interface type | RS-232/422/485 |
| Flow control support | Yes |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Certification | RoHS, WEEE, FCC, UL, METL, TAA, AEO |
| Baud rate | 1000 Kbit/s |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Cabling technology | 10/100/1000Base-T(X) |
| Weight & dimensions | |
| Package width | 22.6 mm |
| Package length | 11.4 cm |
| Package height | 99 mm |
| Weight | 108 g |
| Dimensions (WxDxH) | 96.3 x 101 x 25 mm |
| Power | |
| Power consumption | 60 mA |
| Input voltage | 5 - 30 V |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating temperature (T-T) | -30 - 80 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Protocols | |
| Supported network protocols | ICMP, IP, TCP, UDP, DHCP, BOOTP, Telnet, HTTP, RFC2217 |
| Certificates | |
| Certification | RoHS, WEEE, FCC, UL, METL, TAA, AEO |
| Indication | |
| LED indicators | Yes |
| Design | |
| Certification | RoHS, WEEE, FCC, UL, METL, TAA, AEO |
Lenovo ES-511 serial server RS-232/422/485
£69.06
