Lenovo Intel Xeon 6766E processor 1.9 GHz 108 MB
Product overview & specifications
ThinkSystem SR630 V4 Intel Xeon 6766E 144C 250W 1.9GHz Processor w/o Fan
| Processor | |
|---|---|
| Processor base frequency | 1.9 GHz |
| Processor manufacturer | Intel |
| Cooler included | No |
| Thermal Design Power (TDP) | 250 W |
| Processor cache | 108 MB |
| Processor model | 6766E |
| Processor threads | 144 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 2.7 GHz |
| Processor lithography | 3 nm |
| Processor family | Intel® Xeon® |
| Processor cores | 144 |
| Processor socket | LGA 4710 |
| Intel® UPI Speed | 24 GT/s |
| Memory | |
| Maximum internal memory supported by processor | 4 TB |
| Memory types supported by processor | DDR5-SDRAM |
| Memory clock speeds supported by processor | 6400 MHz |
| Memory channels | Octa-channel |
| ECC | Yes |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card model | Not available |
| Power | |
| Thermal Design Power (TDP) | 250 W |
| Technical details | |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Execute Disable Bit | Yes |
| PCI Express slots version | 5.0 |
| Supported instruction sets | AVX 2.0 |
| Scalability | 2S |
| Embedded options available | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Thermal Design Power (TDP) | 250 W |
| Market segment | Server |
| Launch date | Q2'24 |
| Intel Virtualization Technology (VT-x) | Yes |
| Number of UPI links | 4 |
| Package carrier | E2B |
| Features | |
| Maximum number of PCI Express lanes | 88 |
| Thermal Design Power (TDP) | 250 W |
| Execute Disable Bit | Yes |
| PCI Express slots version | 5.0 |
| Supported instruction sets | AVX 2.0 |
| Scalability | 2S |
| Embedded options available | Yes |
| Market segment | Server |
| Processor special features | |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Intel® OS Guard | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel® Boot Guard | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Maximum Enclave Size Support for Intel® SGX | 512 GB |
| Intel® Platform Firmware Resilience Support | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Total Memory Encryption - Multi Key | Yes |
| Intel® QuickAssist Software Acceleration | Yes |
| Intel® QuickAssist Technology (QAT) | 2 |
| Intel® Dynamic Load Balancer (DLB) | 2 |
| Intel® Data Streaming Accelerator (DSA) | 2 |
| Intel® In-memory Analytics Accelerator (IAA) | 2 |
| Intel® Trust Domain Extensions (Intel® TDX) | Yes |
| Operational conditions | |
| Tcase | 84 °C |
| DTS Max | 101 °C |
