Lenovo Intel Xeon Gold 6554S processor 2.2 GHz 180 MB
Product overview & specifications
ThinkSystem SR650 V3 Intel Xeon Gold 6554S 36C 270W 2.2GHz Processor Option Kit w/o Fan
| Processor | |
|---|---|
| Processor generation | Intel Xeon Scalable 5th Gen |
| Processor base frequency | 2.2 GHz |
| Processor manufacturer | Intel |
| Cooler included | No |
| Thermal Design Power (TDP) | 270 W |
| Processor cache | 180 MB |
| Processor model | 6554S |
| Processor threads | 72 |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4 GHz |
| Processor lithography | 7 nm |
| Processor family | Intel® Xeon® Gold |
| Processor cores | 36 |
| Processor socket | LGA 4677 (Socket E) |
| Processor series | Intel Xeon Gold 6000 Series |
| High priority cores | 12 |
| High priority core frequency | 2.4 GHz |
| Low priority cores | 24 |
| Low priority core frequency | 2 GHz |
| Intel® UPI Speed | 20 GT/s |
| Memory | |
| Maximum internal memory supported by processor | 4 TB |
| Memory types supported by processor | DDR5-SDRAM |
| Memory clock speeds supported by processor | 5200 MHz |
| Memory channels | Octa-channel |
| ECC | Yes |
| Non-ECC | No |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card model | Not available |
| Power | |
| Thermal Design Power (TDP) | 270 W |
| Technical details | |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Trusted Execution Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Execute Disable Bit | Yes |
| PCI Express slots version | 5.0 |
| Supported instruction sets | AMX, AVX, AVX 2.0, AVX-512, SSE4.2 |
| Scalability | 2S |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Embedded options available | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Thermal Design Power (TDP) | 270 W |
| Processor series | Intel Xeon Gold 6000 Series |
| Market segment | Server |
| Launch date | Q4'23 |
| Intel Virtualization Technology (VT-x) | Yes |
| Number of UPI links | 4 |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Package carrier | E1A |
| Servicing status | Baseline Servicing |
| Features | |
| Maximum number of PCI Express lanes | 80 |
| Thermal Design Power (TDP) | 270 W |
| Execute Disable Bit | Yes |
| PCI Express slots version | 5.0 |
| Supported instruction sets | AMX, AVX, AVX 2.0, AVX-512, SSE4.2 |
| Scalability | 2S |
| Embedded options available | Yes |
| Market segment | Server |
| Use conditions | Server/Enterprise |
| Processor special features | |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel 64 | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® OS Guard | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Intel Trusted Execution Technology | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
| Intel® Boot Guard | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Run Sure Technology | Yes |
| Intel® Resource Director Technology (Intel® RDT) | Yes |
| Intel® Speed Select Technology - Base Frequency (Intel® SST-BF) | Yes |
| Intel® Transactional Synchronization Extensions | Yes |
| Intel® Total Memory Encryption | Yes |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Platform Firmware Resilience Support | Yes |
| Intel® Crypto Acceleration | Yes |
| Intel® Total Memory Encryption - Multi Key | Yes |
| Intel® QuickAssist Software Acceleration | Yes |
| Intel® QuickAssist Technology (QAT) | 4 |
| Intel® Dynamic Load Balancer (DLB) | 4 |
| Intel® Data Streaming Accelerator (DSA) | 4 |
| Intel® Advanced Matrix Extensions (AMX) | Yes |
| Intel® Speed Select Technology – Core Power | Yes |
| Intel® Speed Select Technology – Turbo Frequency | Yes |
| Intel® Trust Domain Extensions (Intel® TDX) | Yes |
| Operational conditions | |
| Tcase | 74 °C |
| DTS Max | 91 °C |
