HP Intel Xeon Gold 5220R processor 2.2 GHz 35.75 MB L3 Tray
Product overview & specifications
HP Intel Xeon Gold 5220R, Intel® Xeon® Gold, LGA 3647 (Socket P), 14 nm, Tray, Intel, 5220R
HP Intel Xeon Gold 5220R. Processor family: Intel® Xeon® Gold, Processor socket: LGA 3647 (Socket P), Processor lithography: 14 nm. Memory channels: Hexa-channel, Maximum internal memory supported by processor: 1 TB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, Scalability: 2S. Compatibility: DL380 G10
| Processor | |
|---|---|
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor base frequency | 2.2 GHz |
| Processor manufacturer | Intel |
| Cooler included | No |
| Processor codename | Cascade Lake |
| Thermal Design Power (TDP) | 150 W |
| Processor cache | 35.75 MB |
| Processor model | 5220R |
| Processor threads | 48 |
| System bus rate | 10.4 GT/s |
| Processor operating modes | 64-bit |
| Processor boost frequency | 4 GHz |
| Component for | Server/workstation |
| Processor lithography | 14 nm |
| Processor family | Intel® Xeon® Gold |
| Processor cores | 24 |
| Processor socket | LGA 3647 (Socket P) |
| Processor series | Intel Xeon Gold 5000 Series |
| Processor cache type | L3 |
| Package type | Tray |
| Memory | |
| Maximum internal memory supported by processor | 1 TB |
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2667 MHz |
| Memory channels | Hexa-channel |
| ECC | Yes |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card model | Not available |
| On-board graphics card | No |
| Discrete graphics card model | Not available |
| Power | |
| Thermal Design Power (TDP) | 150 W |
| Technical details | |
| PCI Express slots version | 3.0 |
| Scalability | 2S |
| Thermal Design Power (TDP) | 150 W |
| Processor series | Intel Xeon Gold 5000 Series |
| Market segment | Server |
| Processor cache type | L3 |
| Features | |
| Maximum number of PCI Express lanes | 48 |
| Thermal Design Power (TDP) | 150 W |
| PCI Express slots version | 3.0 |
| Scalability | 2S |
| Market segment | Server |
| Harmonized System (HS) code | 85423119 |
| Packaging data | |
| Package type | Tray |
| Logistics data | |
| Harmonized System (HS) code | 85423119 |
| Other features | |
| Compatibility | DL380 G10 |
