Product overview & specifications
5th/4th Gen Intel Xeon Scalable - 2U UP 12-Bay SATA/SAS Titanium
Accelerating Artificial Intelligence and Leading Efficiency
Engineering richer features in a revolutionary platform, Intel has made an incredible jump in processor performance in the business transformation journey. AI and deep learning performance will benefit from the built-in AI acceleration engines, while networking, storage, and analytics leverage other specialized accelerators in the 4th & 5th Gen Intel Xeon Scalable processors. Adding a host of new features to target a wide range of workloads, the new families of Intel Xeon processors will deliver even better CPU performance and performance per watt, and do so on a PCIe 5.0 platform with 2x the prior gen throughput to greatly speed up data movement to and from GPUs and storage. Intel also created the Intel Xeon CPU Max Series with High Bandwidth Memory (HBM) for improvements in memory bound HPC and AI workloads. For this new platform, GIGABYTE has products ready to get the most out of Intel Xeon CPU-based systems that support fast PCIe Gen5 accelerators and Gen5 NVMe drives, in addition to support for high performant DDR5 memory.
Hard drive
RAID levels 0, 1, 5, 10
Hot-swap HDD bays Yes
Processor
Built-in processor No
Processor socket LGA 4677 (Socket E)
Processor family Intel® Xeon®
Number of processors supported 2
Motherboard chipset Intel C741
Compatible processor series Intel® Xeon®
Processor manufacturer Intel
Design
80 PLUS certification 80 PLUS Titanium
Reset button Yes
On/off switch Yes
Number of fans 4 fan(s)
Fan diameter 8 cm
LED indicators HDD, LAN, Power, System
Product colour Black, Grey
Chassis type Rack (2U)
Cooling type Active
Memory
Supported RDIMM clock speeds 5600,4400 MHz
Supported memory types GDDR5
Number of DIMM slots 16
Memory channels Octa-channel
Storage
Number of storage drives supported 13
Number of 3.5" bays 12
Number of 2.5" bays 12
RAID levels 0, 1, 5, 10
Hot-swap HDD bays Yes
Storage drive sizes supported 2.5,3.5"
Performance
Trusted Platform Module (TPM) Yes
Backplanes support Yes
Graphics
On-board graphics card model Aspeed AST2600
Network
LAN controller Intel® I210-AT
Ethernet LAN data rates 10,100,1000 Mbit/s
Ethernet LAN Yes
Ethernet interface type Gigabit Ethernet
Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
USB 2.0 ports quantity 0
Ethernet LAN (RJ-45) ports 1
Mini DisplayPorts quantity 1
Expansion slots
Number of M.2 (M) slots 1
Features
Trusted Platform Module (TPM) Yes
Backplanes support Yes
Technical details
Packaging content 1 x R263-S30-AAH2 1 x CPU heatsink 1 x Mini-DP to D-Sub cable 3 x Carriers 1 x 2-Section Rail ki
Number of storage drives supported 13
Number of 3.5" bays 12
Number of 2.5" bays 12
Reset button Yes
On/off switch Yes
Number of fans 4 fan(s)
Fan diameter 8 cm
Trusted Platform Module (TPM) Yes
Chassis type Rack (2U)
Backplanes support Yes
Colour
Product colour Black, Grey
Indication
LED indicators HDD, LAN, Power, System
Power
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Input current 12 - 8 A
Number of main power supplies 2
Power supply 1300 W
80 PLUS certification 80 PLUS Titanium
Operational conditions
Storage temperature (T-T) -40 - 60 °C
Storage relative humidity (H-H) 5 - 95%
Operating temperature (T-T) 10 - 35 °C
Operating relative humidity (H-H) 8 - 80%
Weight & dimensions
Width 438 mm
Weight 26 kg
Height 87.5 mm
Depth 710 mm
Package weight 27.5 kg
Package width 989 mm
Package depth 594 mm
Package height 279 mm
Packaging data
Packaging content 1 x R263-S30-AAH2 1 x CPU heatsink 1 x Mini-DP to D-Sub cable 3 x Carriers 1 x 2-Section Rail ki
Package weight 27.5 kg
Package width 989 mm
Package depth 594 mm
Package height 279 mm
Other features
Reset button Yes
