Lenovo ThinkCentre neo 55s Gen 6 AMD Ryzen™ 5 220 8 GB DDR5-SDRAM 256 GB SSD Windows 11 Pro SFF PC Black
Product overview & specifications
AMD Ryzen 5 220 (6C/12T, 3.2/4.9GHz, 6MB L2/16MB L3), 1x 8GB SODIMM DDR5-5600, 256GB SSD M.2 2280 PCIe 4.0x4 NVMe Opal 2.0, AMD Radeon 740M Graphics, Windows 11 Pro
Small Size, Purposeful Performance
A small form factor (SFF) PC that optimizes business productivity & performance at all levels.
- Powerful performance with AMD RyzenT 200 Series processors
- Multiple connectivity options to facilitate multitasking & workflows
- Expandable memory & storage to support business growth
Windows support for peripheral Enhanced sign-in security (ESS) fingerprint sensors is coming in late 2025! Some Windows Hello peripheral devices may already be available in market. For those who would like to use these fingerprint readers with ESS before it is officially supported in Windows, we recommend plugging in the fingerprint reader before booting the device for the first time, enrolling in Windows Hello during the Windows Out of the Box Experience (OOBE), and never detaching the sensor from the PC.
Specifications
| Processor | |
|---|---|
| Processor frequency | 3.2 GHz |
| Processor model | 220 |
| Processor manufacturer | AMD |
| Processor boost frequency | 4.9 GHz |
| Processor threads | 12 |
| Processor cores | 6 |
| L3 cache | 16 MB |
| L2 cache | 6 MB |
| Processor family | AMD RyzenT 5 |
| Memory | |
| Memory layout (slots x size) | 1 x 8 GB |
| Internal memory | 8 GB |
| Maximum internal memory | 64 GB |
| Memory slots | 2x SO-DIMM |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 5600 MHz |
| Storage | |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Optical drive type | No |
| SSD interface | PCI Express 4.0 |
| SSD capacity | 256 GB |
| Number of SSDs installed | 1 |
| Card reader integrated | No |
| Total storage capacity | 256 GB |
| SSD form factor | M.2 |
| Total SSDs capacity | 256 GB |
| NVMe | Yes |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Graphics | |
| Discrete graphics card | No |
| On-board graphics card family | AMD Radeon |
| On-board graphics card | Yes |
| Discrete graphics card model | Not available |
| On-board graphics card model | AMD Radeon 740M |
| On-board GPU manufacturer | AMD |
| Optical drive | |
| Optical drive type | No |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Ethernet LAN data rates | 100,1000 Mbit/s |
| Ports & interfaces | |
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 0 |
| Thunderbolt 3 ports quantity | 0 |
| HDMI version | 2.1 |
| USB 2.0 ports quantity | 2 |
| Microphone in | Yes |
| Line-out | Yes |
| HDMI ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| DisplayPorts quantity | 1 |
| Technical details | |
| Cable lock slot type | Kensington |
| Product type | PC |
| Trusted Platform Module (TPM) | Yes |
| Product colour | Black |
| Chassis type | SFF |
| Audio system | High Definition Audio |
| Cable lock slot | Yes |
| Motherboard chipset | AMD SoC |
| Design | |
| Volume | 8.2 L |
| Cable lock slot type | Kensington |
| Product colour | Black |
| Chassis type | SFF |
| Cable lock slot | Yes |
| Colour name | Raven Black |
| Performance | |
| Audio chip | Realtek ALC623 |
| Number of speakers | 1 |
| Product type | PC |
| Trusted Platform Module (TPM) | Yes |
| Audio system | High Definition Audio |
| Built-in speaker(s) | Yes |
| Motherboard chipset | AMD SoC |
| Fingerprint reader | No |
| Software | |
| Operating system language | English |
| Operating system installed | Windows 11 Pro |
| Power | |
| Power supply | 200 W |
| Certificates | |
| Certification | ENERGY STAR,TCO,RoHS |
| Weight & dimensions | |
| Volume | 8.2 L |
| Width | 89 mm |
| Depth | 274.8 mm |
| Height | 336 mm |
| Weight | 4.33 kg |
| Packaging content | |
| Mouse included | Yes |
| Keyboard included | Yes |
| Mouse connectivity | Wired |
| Keyboard connectivity | Wired |
| Other features | |
| Number of speakers | 1 |
| Trusted Platform Module (TPM) | Yes |
| On-board graphics card | Yes |
| Processor manufacturer | AMD |
| Built-in speaker(s) | Yes |
