Lenovo Legion T5 30IAS10 Intel Core Ultra 7 265KF 32 GB DDR5-SDRAM 1 TB SSD NVIDIA GeForce RTX 5070 Ti Windows 11 Home Tower PC Black
Product overview & specifications
Intel Core Ultra 7 265KF (30MB Cache), 32GB DDR5-SDRAM, 1000GB SSD, NVIDIA GeForce RTX 5070 Ti (16GB GDDR7), LAN, WLAN, Bluetooth, Windows 11 Home
Specifications
| Processor | |
|---|---|
| Processor generation | Intel Core Ultra (Series 2) |
| Processor cache type | Smart Cache |
| Processor cache | 30 MB |
| Processor model | 265KF |
| Number of processors installed | 1 |
| Processor manufacturer | Intel |
| Processor boost frequency | 5.5 GHz |
| Processor threads | 20 |
| Processor cores | 20 |
| Processor family | Intel Core Ultra 7 |
| Performance cores | 8 |
| Efficient cores | 12 |
| Performance-core base frequency | 3.9 GHz |
| Efficient-core base frequency | 3.3 GHz |
| Processor base power | 125 W |
| Maximum turbo power | 250 W |
| Efficient-core Max Turbo Frequency | 4.6 GHz |
| Performance-core Max Turbo Frequency | 5.4 GHz |
| Neural processor unit (NPU) | |
| Neural processor unit (NPU) | Intel AI Boost |
| Sparsity support | Yes |
| Windows Studio effects support | Yes |
| AI software frameworks supported by NPU | DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to | 25 TOPs |
| NPU performance up to | 13 TOPs |
| Memory | |
| Non-ECC | Yes |
| Memory layout (slots x size) | 2 x 16 GB |
| Internal memory | 32 GB |
| Maximum internal memory | 64 GB |
| Memory slots | 4x DIMM |
| Internal memory type | DDR5-SDRAM |
| Memory clock speed | 5600 MHz |
| Memory channels | Dual-channel |
| Storage | |
| Storage media | SSD |
| Number of storage drives installed | 1 |
| Optical drive type | No |
| SSD interface | PCI Express 4.0 |
| SSD capacity | 1 TB |
| Number of SSDs installed | 1 |
| Card reader integrated | No |
| Total storage capacity | 1 TB |
| SSD form factor | M.2 |
| Total SSDs capacity | 1 TB |
| NVMe | Yes |
| M.2 SSD size | 2280 (22 x 80 mm) |
| Graphics | |
| Discrete graphics card | Yes |
| Discrete graphics card memory | 16 GB |
| On-board graphics card | No |
| Discrete graphics card model | NVIDIA GeForce RTX 5070 Ti |
| Discrete graphics memory type | GDDR7 |
| On-board graphics card model | Not available |
| Number of discrete graphics cards | 1 |
| Discrete GPU manufacturer | NVIDIA |
| Performance | |
| Market positioning | Gaming |
| Password protection | Yes |
| Password protection type | BIOS, HDD |
| Product type | PC |
| Trusted Platform Module (TPM) | Yes |
| Audio output channels | 5.1 channels |
| Motherboard chipset | Intel B860 |
| Trusted Platform Module (TPM) version | 2.0 |
| Audio chip | Realtek ALC623 |
| Audio system | High Definition Audio |
| Optical drive | |
| Optical drive type | No |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth | Yes |
| Bluetooth version | 5.4 |
| Wi-Fi standards | Wi-Fi 7 (802.11be) |
| Ethernet LAN data rates | 2500 Mbit/s |
| Top Wi-Fi standard | Wi-Fi 7 (802.11be) |
| Antenna type | 2x2 |
| LAN controller | Dragon RTL8125BG |
| Ports & interfaces | |
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Thunderbolt 3 ports quantity | 0 |
| USB 2.0 ports quantity | 4 |
| Line-out | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Expansion slots | |
| PCI Express x4 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| Power | |
| Power supply input frequency | 50/60 Hz |
| Power supply input voltage | 100 - 240 V |
| Power supply | 850 W |
| Technical details | |
| Water cooling system | Yes |
| Product type | PC |
| Trusted Platform Module (TPM) | Yes |
| Product colour | Black |
| Chassis type | Tower |
| Audio system | High Definition Audio |
| Placement supported | Vertical |
| Audio output channels | 5.1 channels |
| Motherboard chipset | Intel B860 |
| Compliance certificates | RoHS |
| Design | |
| Volume | 30 L |
| Water cooling system | Yes |
| Product colour | Black |
| Chassis type | Tower |
| Placement supported | Vertical |
| Viewing window | Yes |
| Colour name | Eclipse black |
| Software | |
| Operating system language | German |
| Operating system architecture | 64-bit |
| Operating system installed | Windows 11 Home |
| Display | |
| Display included | No |
| Audio | |
| Audio chip | Realtek ALC623 |
| Audio system | High Definition Audio |
| Operational conditions | |
| Operating altitude | 0 - 3048 m |
| Storage temperature (T-T) | -40 - 60 �C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 35 �C |
| Non-operating altitude | 0 - 12192 m |
| Weight & dimensions | |
| Volume | 30 L |
| Package width | 321 mm |
| Package depth | 596 mm |
| Package height | 549 mm |
| Width | 211 mm |
| Depth | 490.4 mm |
| Height | 414 mm |
| Package weight | 17 kg |
| Weight | 15 kg |
| Packaging data | |
| Package width | 321 mm |
| Package depth | 596 mm |
| Package height | 549 mm |
| Package weight | 17 kg |
| Packaging content | |
| Mouse included | No |
| Keyboard included | No |
| Display included | No |
| Certificates | |
| Certification | RoHS |
| Compliance certificates | RoHS |
| Other features | |
| Trusted Platform Module (TPM) | Yes |
| On-board graphics card | No |
| Processor manufacturer | Intel |
